2010 - 2016 Audi S4/S5 3.0t Ecu Tune (Remote)
Stage Power Comparison
All mods recommended
E40: 471 WHP / 440 WTQ
E40: 500 WHP / 470 WTQ
BDT Stage 1 ECU Tune
2009–2016 Audi S4 / S5 3.0T Supercharged (B8 / B8.5)
BDT delivers real, measurable results — not inflated marketing numbers. Our Stage 1 calibration delivers 426 WHP / 400 WTQ on 93 octane with live, transparent dyno testing. Rev limit raised to 7200 RPM. Crackle pops in Dynamic mode. No required mods.

Fitment & Compatibility
Vehicle: 2009–2016 Audi S4 / S5 3.0T (B8 / B8.5)
Engine: 3.0T TFSI Supercharged V6
- Quattro AWD
- Automatic & Manual supported
- 91–93 octane (E40 available on S2/S3)
- Remote OBDII flashing compatible
Stage 1 Highlights
- 426 WHP / 400 WTQ on 93 octane
- Rev limit raised to 7200 RPM
- Speed limiter removed
- Neutral/Park rev limiter raised
- Torque limiters raised
- Fueling optimized by throttle position
- Refined boost control — linear onset
- Supercharger lag reduced
- LPFP/HPFP targets optimized
- VVT recalibrated
- Crackle Pops (Dynamic mode, Low / Medium / Intense)
- OBDII port flashing
Power Gains
| Stage | WHP | WTQ |
|---|---|---|
| Stock Audi Advertised | 333 HP | 325 TQ |
| Stock BDT Dyno | 305 WHP | 311 WTQ |
| Stage 1 93 Octane | 426 WHP | 400 WTQ |
| Stage 2 93 Octane | 445 WHP | 420 WTQ |
| Stage 2 E40 | 471 WHP | 440 WTQ |
| Stage 3 93 Octane | 475 WHP | 445 WTQ |
| Stage 3 E40 | 500 WHP | 470 WTQ |
Stage 1 Modification Requirements
Stage 1 requires no hardware modifications. All mods below are recommended.
Upgrade Matrix
| Part / Upgrade | Required | Recommended |
|---|---|---|
| TCU Tune | — | HIGHLY REC. |
| Air Intake | — | YES |
| Heat Exchanger | — | YES |
| Drivetrain Inserts | — | YES |
| High-Flow Exhaust | — | YES |
| Supercharger Pulley | — | YES |
| Crank Pulley | — | REC. |
| Throttle Body Upgrade | — | NOT COMPATIBLE |
| Spark Plugs NGK BKR9EIX .024 | — | HIGHLY REC. |
B8 S4/S5 DYNO + DEMO
B8 S4/S5 PULLS
BDT Stage 2 ECU Tune
2009–2016 Audi S4 / S5 3.0T Supercharged (B8 / B8.5)
Stage 2 pushes the supercharged 3.0T further with supporting hardware. 445 WHP / 420 WTQ on 93 octane or 471 WHP / 440 WTQ on E40. Rev limit raised to 7200 RPM. Crackle pops in Dynamic mode.
Stage 2 Highlights
- 445 WHP / 420 WTQ (93 octane)
- 471 WHP / 440 WTQ (E40 ethanol)
- Rev limit raised to 7200 RPM
- Speed limiter removed
- Torque model recalibrated
- Refined boost control
- Supercharger lag reduced
- LPFP/HPFP optimized
- VVT recalibrated
- Crackle Pops (Dynamic, Low / Medium / Intense)
- OBDII port flashing
Mod Requirements
| Part | Req. | Rec. |
|---|---|---|
| Supercharger Pulley | YES | — |
| Heat Exchanger | YES | — |
| Spark Plugs NGK BKR9EIX .024 | YES | — |
| TCU Tune | — | HIGHLY REC. |
| Air Intake | — | YES |
| Drivetrain Inserts | — | YES |
| Crank Pulley | — | REC. |
| High-Flow Exhaust | NOT REQUIRED | — |
| Throttle Body Upgrade | — | NOT COMPATIBLE |
BDT Stage 3 ECU Tune
2009–2016 Audi S4 / S5 3.0T Supercharged (B8 / B8.5)
Stage 3 delivers the absolute ceiling of performance from Audi's legendary 3.0T supercharged platform. 475 WHP / 445 WTQ on 93 octane or 500 WHP / 470 WTQ on E40. Advanced dual-pulley boost control strategy. This is the calibration designed to dominate.
Stage 3 Highlights
- 475 WHP / 445 WTQ (93 octane)
- 500 WHP / 470 WTQ (E40 ethanol)
- Rev limit raised to 7200 RPM
- Advanced dual-pulley boost control
- Linear, sustained boost across entire powerband
- Torque model fully recalibrated
- Enhanced thermal management logic
- LPFP/HPFP optimized
- VVT recalibrated
- Crackle Pops (Dynamic, Low / Medium / Intense)
- OBDII port flashing
Mod Requirements
| Part | Req. | Rec. |
|---|---|---|
| TCU Tune | YES | — |
| Air Intake | YES | — |
| Heat Exchanger | YES | — |
| Supercharger Pulley | YES | — |
| Crank Pulley | YES | — |
| Bigger Throttle Body | YES | — |
| Spark Plugs NGK BKR9EIX .024 | YES | — |
| Ethanol Content Sensor (for E40) | — | REC. |
How Remote Tuning Works — Flash From Home
No shop. No downtime. BDT connects via TeamViewer, walks you through reading your stock ECU, then flashes the updated calibration in real time. You're on a live session with the actual tuner.
- 1
Schedule your flash session after purchase.
- 2
Download TeamViewer Quick Support.
- 3
Connect battery charger: 10–25 amps.
- 4
Key on, engine off.
- 5
Plug in the interface — OBDII port to USB.
- 6
Share your TeamViewer ID. BDT handles everything.
- 7
Key off on command. Fault codes clear on their own.
- 8
Disconnect & drive.
Frequently Asked Questions
Q: What's the difference between Stage 1, 2, and 3?
A: Stage 1 requires no hardware. Stage 2 adds a supercharger pulley, heat exchanger, and spark plugs. Stage 3 is a full dual-pulley build with TCU, intake, bigger throttle body, and all Stage 2 hardware.
Q: Do I need a TCU tune?
A: Highly recommended for Stage 1 and 2. Required for Stage 3. The TCU tune raises torque limits and improves shift behavior.
Q: Does it support E40 ethanol?
A: Yes. E40 support is available on Stage 2 and Stage 3. An ethanol content sensor is recommended for E40.
Q: Are these WHP or crank numbers?
A: All power figures are wheel horsepower (WHP) measured on BDT's dyno with transparent before-and-after runs.
Q: Can I flash at home?
A: Yes. 100% remote with live support. A Windows laptop is required.
