Select Stage: Stage 1 Stage 2 Stage 3

Stage Power Comparison

2014–2017 Audi SQ5 3.0T Supercharged • Quattro AWD

Stage 1

426

WHP / 93 Octane

400 WTQ

No hardware required
All mods recommended

View Stage 1 →

Stage 2
445
WHP / 93 Octane
420 WTQ
Pulley + heat exchanger + plugs req.
E40: 471 WHP / 440 WTQ
View Stage 2 →

Stage 3

475

WHP / 93 Octane

445 WTQ

Full dual-pulley build required
E40: 500 WHP / 470 WTQ

View Stage 3 →

BOOST DYNAMIC TUNING

BDT Stage 1 ECU Tune

2014–2017 Audi SQ5 3.0T Supercharged

BDT delivers real, measurable results — not inflated marketing numbers. Our Stage 1 calibration delivers 426 WHP / 400 WTQ on 93 octane with live, transparent dyno testing. Rev limit raised to 7200 RPM. Crackle pops in Dynamic mode. No required mods.

Get ready to put those unsuspecting Hellcat challengers in their place, leaving them in your rearview mirror with dented pride and a newfound respect.

Quattro AWD Supercharged 3.0T 7200 RPM Rev Limit Crackle Pops Remote OBDII Flash

Fitment & Compatibility

Vehicle: 2014–2017 Audi SQ5 3.0T

Engine: 3.0T TFSI Supercharged V6

Quattro AWD
ZF 8-speed automatic
91–93 octane (E40 available on S2/S3)
Remote OBDII flashing compatible

Stage 1 Highlights

426 WHP / 400 WTQ on 93 octane
Rev limit raised to 7200 RPM
Speed limiter removed
Neutral/Park rev limiter raised
Torque limiters raised
Fueling optimized by throttle position
Refined boost control — linear onset
Supercharger lag reduced
LPFP/HPFP targets optimized
VVT recalibrated
Crackle Pops (Dynamic mode, Low / Medium / Intense)
OBDII port flashing

Crackle Pops — Add Some Drama

When you decelerate from high RPMs or rev freely in neutral or park, you'll hear that exhilarating crackle and pop from your exhaust. It's the perfect way to add an extra dash of excitement to your already captivating exhaust sound!

Three crackle levels:

Low — Subtle, refined pops for daily driving
Medium — Noticeable and fun, turns heads
High/Intense — Flames possible with free-flowing exhaust

Crackle pops activate in Dynamic mode only. RPM dependent. Less noticeable on stock exhaust — aftermarket exhaust recommended for maximum effect.

Power Gains

Stage	WHP	WTQ
Stock Audi Advertised	333 HP	325 TQ
Stock BDT Dyno	305 WHP	311 WTQ
Stage 1 93 Octane	426 WHP	400 WTQ
Stage 2 93 Octane	445 WHP	420 WTQ
Stage 2 E40	471 WHP	440 WTQ
Stage 3 93 Octane	475 WHP	445 WTQ
Stage 3 E40	500 WHP	470 WTQ

Stage 1 Modification Requirements

Stage 1 requires no hardware modifications. All mods below are recommended.

Upgrade Matrix

Part / Upgrade	Required	Recommended
TCU Tune	—	HIGHLY REC.
Air Intake	—	YES
Heat Exchanger	—	YES
Drivetrain Inserts	—	YES
High-Flow Exhaust	—	YES
Supercharger Pulley	—	YES
Crank Pulley	—	REC.
Throttle Body Upgrade	—	NOT COMPATIBLE
Spark Plugs NGK BKR9EIX .024	—	HIGHLY REC.

SQ5 DYNO + DEMO

SQ5 PULLS

BOOST DYNAMIC TUNING

BDT Stage 2 ECU Tune

2014–2017 Audi SQ5 3.0T Supercharged

Stage 2 pushes the supercharged 3.0T further with supporting hardware. 445 WHP / 420 WTQ on 93 octane or 471 WHP / 440 WTQ on E40. Rev limit raised to 7200 RPM. Crackle pops in Dynamic mode.

SC Pulley + HEX Req. Quattro AWD E40 Support Crackle Pops

Stage 2 Requirements: Supercharger pulley, heat exchanger, and spark plugs required.

Stage 2 Highlights

445 WHP / 420 WTQ (93 octane)
471 WHP / 440 WTQ (E40 ethanol)
Rev limit raised to 7200 RPM
Speed limiter removed
Torque model recalibrated
Refined boost control
Supercharger lag reduced
LPFP/HPFP optimized
VVT recalibrated
Crackle Pops (Dynamic, Low / Medium / Intense)
OBDII port flashing

Mod Requirements

Part	Req.	Rec.
Supercharger Pulley	YES	—
Heat Exchanger	YES	—
Spark Plugs NGK BKR9EIX .024	YES	—
TCU Tune	—	HIGHLY REC.
Air Intake	—	YES
Drivetrain Inserts	—	YES
Crank Pulley	—	REC.
High-Flow Exhaust	NOT REQUIRED	—
Throttle Body Upgrade	—	NOT COMPATIBLE

BOOST DYNAMIC TUNING

BDT Stage 3 ECU Tune

2014–2017 Audi SQ5 3.0T Supercharged

Stage 3 delivers the absolute ceiling of performance from Audi's legendary 3.0T supercharged platform. 475 WHP / 445 WTQ on 93 octane or 500 WHP / 470 WTQ on E40. Advanced dual-pulley boost control strategy. This is the calibration designed to dominate.

Full Dual-Pulley Build Quattro AWD E40 Support Crackle Pops

Stage 3 is a full dual-pulley build. TCU tune, intake, heat exchanger, SC pulley, crank pulley, bigger throttle body, and spark plugs all required.

Stage 3 Highlights

475 WHP / 445 WTQ (93 octane)
500 WHP / 470 WTQ (E40 ethanol)
Rev limit raised to 7200 RPM
Advanced dual-pulley boost control
Linear, sustained boost across entire powerband
Torque model fully recalibrated
Enhanced thermal management logic
LPFP/HPFP optimized
VVT recalibrated
Crackle Pops (Dynamic, Low / Medium / Intense)
OBDII port flashing

Mod Requirements

Part	Req.	Rec.
TCU Tune	YES	—
Air Intake	YES	—
Heat Exchanger	YES	—
Supercharger Pulley	YES	—
Crank Pulley	YES	—
Bigger Throttle Body	YES	—
Spark Plugs NGK BKR9EIX .024	YES	—
Ethanol Content Sensor (for E40)	—	REC.

⚠️ WINDOWS LAPTOP REQUIRED (NO APPLE / MACOS) • STABLE INTERNET • BDT-SUPPLIED TUNING INTERFACE

How Remote Tuning Works — Flash From Home

This is a remote tune — you will be sent a cable to flash the tune. BDT connects via TeamViewer, walks you through reading your stock ECU, then flashes the updated calibration in real time. You're on a live session with the actual tuner.

1
Schedule your flash session after purchase.
2
Download TeamViewer Quick Support.
3
Connect battery charger: 10–25 amps.
4
Key on, engine off.
5
Plug in the interface — OBDII port to USB.
6
Share your TeamViewer ID. BDT handles everything.
7
Key off on command. Fault codes clear on their own.
8
Disconnect & drive.

Late Policy: $50 fee for late arrivals without notice. Reschedules must be made at least 1 hour prior.

Frequently Asked Questions

Q: What's the difference between Stage 1, 2, and 3?
A: Stage 1 requires no hardware. Stage 2 adds a supercharger pulley, heat exchanger, and spark plugs. Stage 3 is a full dual-pulley build with TCU, intake, bigger throttle body, and all Stage 2 hardware.

Q: Do I need a TCU tune?
A: Highly recommended for Stage 1 and 2. Required for Stage 3. The TCU tune raises torque limits and improves shift behavior.

Q: Does it support E40 ethanol?
A: Yes. E40 support is available on Stage 2 and Stage 3. An ethanol content sensor is recommended for E40.

Q: Are these WHP or crank numbers?
A: All power figures are wheel horsepower (WHP) measured on BDT's dyno with transparent before-and-after runs.

Q: Can I flash at home?
A: Yes. 100% remote with live support. A Windows laptop and WiFi are required.

Recommended Maintenance

Component	Interval
Spark Plugs — NGK BKR9EIX gapped .024	Every 15–20K miles
Engine Oil — 5W-40 Full Synthetic + OEM Filter	Every 5K miles
Transmission Service	Every 40K miles
Air Filter	Inspect every 15K miles
Supercharger Service	Every 50K miles

EMISSIONS COMPLIANCE NOTICE & LEGAL DISCLAIMER

FOR COMPETITION USE ONLY — NOT FOR STREET USE

This product is sold and intended solely for vehicles used in closed-course racing, off-road competition, or organized motorsport events. It is not legal for use on any pollution-controlled vehicle operated on public roads or highways, as defined under the Clean Air Act (42 U.S.C. § 7522) and applicable state emissions laws.

Federal and State Emissions Compliance

This product may modify, bypass, defeat, or render inoperative one or more emissions control devices.
Use on emissions-regulated vehicles is strictly prohibited by federal law and may result in penalties up to $45,000 per vehicle under the Clean Air Act.
This product is not certified by the EPA or CARB, and is not legal for sale or use in California or any CARB-adopting state.

Assumption of Risk and Waiver of Liability

Assume all risk and responsibility for compliance with applicable laws.
Waive all claims against Boost Dynamic Tuning, LLC and affiliates.
Release Boost Dynamic Tuning, LLC from damages resulting from improper or unlawful use.

Indemnification Clause

You further agree to indemnify, defend, and hold harmless Boost Dynamic Tuning, LLC from any fines, penalties, damages, losses, or legal fees resulting from use inconsistent with this disclaimer.

Final Notice

This product is sold "as is", with no warranties regarding legality for public highway use. It is the sole responsibility of the end-user to determine legality. Boost Dynamic Tuning, LLC does not condone illegal street use or emissions equipment tampering.

By completing your purchase, you acknowledge that you have read, understood, and agreed to this disclaimer in full.

HIGH-FLOW EXHAUST NOTICE: BY PURCHASING A MOTORSPORT/RACING PRODUCT ("PRODUCT"), YOU REPRESENT THAT YOU UNDERSTAND AND AGREE THAT THE PRODUCT IS NOT DESIGNED TO MEET ANY APPLICABLE EMISSIONS STANDARDS, WHETHER IN THE USA OR OTHERWISE, THE PRODUCT IS NOT DESIGNED TO BE C.A.R.B. COMPLIANT, AND THAT THE PRODUCT IS NOT FOR SALE OR USE IN CALIFORNIA, USA NOR ANY OTHER JURISDICTION WHERE THE SALE OR USE IS PROHIBITED BY LAW.

audi sq5 ecu tune, audi sq5 3.0t supercharged tune, 2014 sq5 tune, 2015 sq5 tune, 2016 sq5 tune, 2017 sq5 tune, sq5 stage 1, sq5 stage 2, sq5 stage 3, sq5 pulley tune, sq5 dual pulley tune, sq5 e40 tune, sq5 supercharger pulley tune, sq5 crackle tune, sq5 overrun tune, sq5 7200 rpm tune, sq5 rev limit tune, sq5 tcu tune, sq5 remote tune, sq5 obd2 flash, boost dynamic tuning sq5, bdt sq5 tune, best sq5 tune, best sq5 tune 2025, best sq5 tune 2026, sq5 426 whp, sq5 445 whp, sq5 475 whp, sq5 500 whp, sq5 heat exchanger tune, b8 sq5 tune, audi q5 3.0t tune, sq5 quattro tune

Reviews

5
Stage 1/TCU TUNE

Posted by J.C on Nov 18th 2025

Wakes up the SQ5 drastically. Well worth the purchase.
